– Professional light-duty photovoltaic drilling design, covers 115-203mm mainstream pile diameter, ideal for medium and small solar farms, slope photovoltaic and open-pit blasting projects.
– 3500Nm high-torque dual-motor rotary system with large reduction ratio, stable rock breaking performance, easily handles f=6-20 hard rock and complex mountain strata.
– Industry-leading 30° super climbing capacity, equipped with enhanced piston walking motor, greatly improves slope adaptability for hilly and rugged photovoltaic construction sites.
– Reinforced track frame and high wear-resistant nylon pressure plate structure, optimized 20A roller chain propulsion system, stable operation and extended service life under long-term outdoor working conditions.
– Standard hydraulic dry dust collection system supports dust-free and low-noise green construction, fully compliant with global new energy and environmental protection construction standards.
– Ultra-light 5.5-ton compact body design, flexible movement and low transportation cost, perfectly adapts to scattered photovoltaic working points and frequent site transition demands.
The Kaishan KG200GF Photovoltaic Open-Pit DTH Drilling Rig is a lightweight and cost-effective professional drilling equipment newly upgraded for medium and small solar farm construction and open-pit blasting projects. Optimized for photovoltaic site characteristics, this model balances lightweight flexibility and high-torque drilling performance, solving the problems of bulky heavy rigs and insufficient power of small ordinary drills.
Powered by a reliable Yuchai four-cylinder diesel engine and equipped with a high-reduction dual-motor rotary system, the KG200GF drill rig delivers stable 3500Nm high torque output. It supports 115-203mm mainstream solar pile drilling diameter and adapts to f=6-20 high-hardness rocks and complex mountain formations, fully meeting foundation drilling and blasting hole construction demands for photovoltaic power stations, water conservancy projects and road engineering.
Featuring an outstanding 30° super climbing capacity and enhanced piston walking motor, this photovoltaic special drill rig exhibits excellent terrain adaptability on steep slopes, hills and rugged mountain sites. The flanged track frame, engineering-grade undercarriage and high-wear-resistance nylon pressure plate effectively improve overall structural stability, ensuring continuous and stable operation in harsh outdoor dusty and high-temperature environments.
Adopting a mature hydraulic dry dust removal system, the KG200GF drilling rig realizes dust-free and low-noise green construction, fully complying with international environmental protection standards for new energy projects. The optimized 3.5m one-time advance length greatly improves single-hole drilling efficiency, speeding up the overall progress of solar farm construction.
With a super-light 5.5-ton compact body, flexible relocation and low daily maintenance cost, the Kaishan KG200GF drill rig is highly cost-effective for medium and small-scale photovoltaic projects and scattered construction sites. It is the most ideal lightweight drilling solution for global solar farm builders and open-pit blasting contractors.
