KJ311 Computer-Aided Intelligent Tunneling Jumbo

KJ311 computer-aided tunneling jumbo is equipped with on-board intelligent PC control system, supporting blast hole plan import, 3D tunnel scanning, auto positioning drilling and construction data storage & upload, cutting overbreak and labor reliance greatly. Standard 360° rotatable dual booms, 17kW high-frequency drifter, 4WD articulated chassis, dual local & remote control, mining Ex & IP65 protection. Fit for 10–32㎡ medium & large roadways with 24/7 intelligent continuous drilling. Full machine, software upgrade and overseas technical export service available.

Full-process computer-aided intelligent control, one-click auto drilling via imported blast layout drawing with high positioning precision
3D laser scan tunnel contour, real-time overbreak calculation to optimize blasting plan
Color touch visual operation, intuitive graphic display of drilling parameters & machine status
Full construction data local storage + remote upload, fully traceable engineering quality
Dual 360° full-range booms, zero blind zone for large sections, stable efficient drilling for soft & hard rock
4WD articulated chassis, flexible relocation in narrow roadways, stable travel on 24° steep slopes
Dual local & wireless remote control, realize man-machine separation in high-risk blasting zones
Mining explosion-proof + IP65 full seal, long-term compliant operation in dusty & gas underground
Large-capacity industrial hydraulic system, match long-hour full auto continuous drilling
Modular intelligent electric unit, separately upgradable hardware & software, easy overseas maintenance
