Product Series: JNP standard dry screw vacuum pump series, multiple power and pumping speed models
Operation Mode: Dry oil-free operation, no lubricant or working water inside pump chamber, pure physical air extraction
Ultimate Vacuum: Standard model 0.1Pa ~ 100Pa, high vacuum model up to 0.01Pa
Pumping Speed: Full range from 10m³/h to 1000m³/h, multiple options
Rotor Structure: Dual parallel screw rotors with high precision machining, no metal contact between rotors
Main Material: Standard cast iron, anti-corrosion model with ductile iron + PTFE coating, premium 316 stainless steel model
Fully dry operation without lubricant or circulating water inside the pump chamber. The extracted gas will not be polluted by oil or water, fully meeting clean process demands of pharmaceutical, food, semiconductor and precision electronic industries. No oil pollution discharge for better environmental protection.
High-precision screw rotors operate without metal contact to minimize wear. Only a small number of wearing parts such as seals and bearings are required. Long maintenance cycle greatly reduces spare parts cost and labor cost, ideal for long-term continuous production.
It works well with fine dust, condensed vapor and weak corrosive medium, breaking the limitations of traditional vacuum pumps. Suitable for complex processes such as chemical solvent recovery, material drying and waste gas extraction. One pump fits multiple production scenarios.
Standard cast iron for general conditions; PTFE anti-corrosion coating for humid and slightly corrosive environments; 316 stainless steel for medium corrosive gas. The integrally cast body is sturdy with excellent pressure and deformation resistance.
Optimized rotor profile and flow channel design deliver high ultimate vacuum and stable pumping speed with small pressure fluctuation. It keeps production process parameters stable and avoids defective products caused by abnormal vacuum.
Excellent dynamic balance design ensures operating noise below 72dB and low vibration. No additional noise reduction equipment is needed, complying with noise standards of overseas factories.
Multi-stage mechanical seals prevent air leakage. Independent anti-backflow valves protect the pump from medium backflow after shutdown. Forced air cooling avoids high-temperature failure. IP54 dust-proof and splash-proof design ensures safe operation under multiple protections.
We support single unit export, bulk supply of standard spare parts and custom complete vacuum units. Complete vacuum systems combined with filters, vacuum tanks, valves and electric control cabinets are available to meet one-stop procurement demands of overseas customers.
