– High-end PTO integrated dual-drive system, powered by 228kW Yuchai six-cylinder engine, one engine drives both air compressor and hydraulic system, ensuring strong power and lower fuel consumption for large-scale mining.
– Equipped with professional 35A/45A high wind pressure DTH hammer, supports 90-138mm wide-range drilling diameter, fast rock breaking speed, perfectly adapts to f=6-20 super hard rock strata.
– Full automatic rod changing and unloading system with 7+1 drill rod storage capacity, realizes uninterrupted continuous drilling, drastically reduces manual labor and improves overall mining efficiency.
– Built-in intelligent anti-jamming protection and automatic drill rod lubrication module, effectively avoids drilling stuck failures, reduces wear of drill bits and rods, and lowers long-term operation costs.
– Adopts floating slide compensation module and optimized roller chain propulsion structure, making drilling operation more stable, reducing vibration and improving borehole straightness.
– 25° super climbing capacity and 430mm high ground clearance, outstanding terrain adaptability, stably coping with steep slopes, rugged and uneven open-pit mine terrains.
– Standard closed air-conditioned cabin isolates dust and noise, providing a safe and comfortable working environment for long-time high-intensity mining operations.
– Professional hydraulic dry dust removal system realizes dust-free green construction, fully compliant with international environmental protection standards for large open-pit mining projects.
The Kaishan ZT10 Integrated Open-Pit DTH Drilling Rig is a high-power intelligent heavy-duty drilling equipment newly upgraded for large-scale open-pit mines, large quarries and high-standard stone blasting projects. Adopting advanced industrial-grade PTO integrated dual-drive technology, this model unifies power unit, high-pressure air compression system and full hydraulic drilling system, solving the low efficiency and complicated operation problems of traditional split drilling rigs.
Powered by a 228kW high-performance Yuchai six-cylinder diesel engine, the ZT10 drill rig provides super strong and stable power reserve for high-intensity mining operations. Matched with 35A/45A professional high wind pressure DTH hammer and 25KN stable propulsion force, it supports 90-138mm wide-range blasting hole drilling and adapts to f=6-20 high-hardness rocks such as granite, basalt and hard limestone, fully meeting the high-efficiency drilling demands of large-scale mining projects.
Equipped with a mature full-automatic rod changing system with 7+1 drill rod storage capacity, the machine realizes automatic feeding, drilling and rod retracting cycles. It greatly reduces manual operation intensity, realizes long-term uninterrupted continuous construction, and significantly improves overall mining production efficiency, which is the core advantage for large-batch mining operations.
The built-in intelligent anti-jamming protection system and automatic drill rod lubrication module monitor the drilling status in real time, effectively preventing hole deviation and drill jamming accidents, reducing the wear and failure rate of wearing parts. The floating slide compensation module and optimized roller chain propulsion structure ensure stable drilling operation, low vibration and high hole forming accuracy.
With 25° excellent climbing capacity and 430mm ultra-high ground clearance, the ZT10 drill rig adapts to various complex rugged terrains of open-pit mines. The closed air-conditioned cabin provides a comfortable and safe operating environment for operators in harsh high-dust and high-temperature working conditions. The standard hydraulic dry dust removal system realizes environmentally friendly dust-free construction, complying with global mining environmental protection policies and project acceptance standards.
With high power, high automation, stable performance and low comprehensive operation cost, Kaishan ZT10 integrated DTH drilling rig is a reliable and high cost-effective heavy-duty drilling solution for large open-pit mines and professional mining contractors worldwide.
