KJ311 Plateau Type Two-Arm Intelligent Tunneling Jumbo

KJ311 plateau type two-arm full hydraulic intelligent tunneling jumbo is a customized upgraded model based on standard KJ311, developed for mines and tunnels at 1000–4500m altitude with low temperature, low oxygen and strong wind & sand. It inherits advantages of 360° full-range drilling, 4WD articulated chassis and full hydraulic intelligent system. Meanwhile, the power, air intake, hydraulic, sealing and electric systems are fully optimized for plateau and alpine conditions.

Equipped with plateau turbocharged diesel engine and multi-stage preheating device, it solves power loss and hard cold start problems. The dual-stage series air filter resists wind and sand. Special low-temperature hydraulic oil and full cold-proof & sand-proof seal ensure stable operation. It supports local lever and wireless remote control, with positioning, auto anti-jamming and self-diagnosis functions. Certified by mining Ex and IP65 standards, it works 24/7 in gas-containing and low-temperature plateau roadways. It is core tunneling equipment for overseas high-altitude mines, plateau traffic tunnels and water projects.

Plateau turbo power, stable at low air pressure
Exhaust turbocharger compensates air intake to reduce power loss. Stable output from 1000m to 450m altitude.
Full low-temperature start capability
Dual intake and cylinder preheating system realizes quick start at -25℃, adapting to long-term cold operation.
Dual-stage air filter, excellent wind & sand resistance
Large filter area efficiently blocks plateau dust and sand to protect engine and precision parts.
Low-temperature resistant hydraulic system
Special hydraulic oil keeps stable viscosity at low temperature, avoiding oil solidification and hydraulic faults in winter.
360° rotatable dual booms, high efficiency for large sections
Full-range rotation & luffing for 10~32㎡ roadways, strong adaptability for soft and hard rock.
4WD articulated chassis, great for plateau terrain
Excellent climbing and obstacle-crossing ability, flexible on steep slopes and gravel roads.
Full intelligent configuration, higher safety
Positioning, anti-jamming, self-diagnosis and remote control realize man-machine separation.
Ex & IP65 full seal, compliant for harsh conditions
Mining explosion-proof, multi-layer seal and thermal insulation for gas, dust, sand and low temperature.
Modular design, easy maintenance in remote plateau
Zoned components and concentrated wearing parts simplify on-site service.
24-hour continuous operation, reliable for projects
Fully tuned for plateau durability, suitable for continuous construction.
